1. Product introduction

By using large quantity of stainless tubes, make sufficient indirect heat exchange between vapors and cooling water. Bigger temperature reduction and better deodorizing performance.

The circulating water cooled down by cooling tower could be used repeatedly, which is especially suitable for factories lack of water.

Heating exchanging pipes are easily to be taken apart for cleaning and removing coking

Series: SCL-1200、SCL-1300、SCL-1500

2. Product parameter

With tublar design, by means of a lot of S.S heating exchange pipe to make sure waste vapor fully contacted with cooling water, maxim heatng exchange area and good deodorizing efficiency.

Using high temperature cooling tower to reduce the temperature of circulating cooling water circulation water cooling is suitable for the area lack of fresh water

using several separate plate so as to ensure cooling water , achieving the best cooling efficiency.

The thrust bearing could enhance the shaft tolerance of declined conveyor; Fitted with wear sleeves to improve the wear resistance, the conveyor could service a longer time.

Main cylindar made of t=4mm S.S, and the foundation made of M.S

The 745 pcs of Heat Exchanger Tubes are made of Ø25*1.2 S.S.

(Dimenion)：7514*1700*2305mm
